Sentinel Plus From Panorama
Superior Exterior Window Film Heat Control
Whether you’re in a high-rise apartment or an office skyscraper, you want to enjoy the sunny days and stunning views, not block them out. With Sentinel Plus from Panorama, you can block harmful solar energy and UV rays to protect your space effectively without losing the natural light.
Key Benefits:
- Maximum heat rejection and glare prevention
- Choose from Stainless Steel, Silver, Clear, and SX
- Blocks up to 82% of total solar energy
- Refreshes and modernizes older building facades
** Window Film Installers is proud to be part of the Panorama Elite Window Film Network, providing the Panorama window film range in New York.
| Specification | Sentinel Plus 4mil Clear | Sentinel Plus DX 15 | Sentinel Plus DX 5 | Sentinel Plus Silver 20 | Sentinel Plus Silver 35 | Sentinel Plus Stainless Steel 15 | Sentinel Plus Stainless Steel 25 | Sentinel Plus Stainless Steel 40 | Sentinel Plus SX50 OSW | Sentinel Plus SX80 OSW |
|---|---|---|---|---|---|---|---|---|---|---|
| Visible light transmittance % | 88% | 14% | 5% | 16% | 33% | 13% | 23% | 38% | 47% | 77% |
| Visible light reflectance (exterior) % | 9% | 42% | 60% | 61% | 41% | 40% | 28% | 18% | 27% | 8% |
| Visible light reflectance (interior) % | 9% | 17% | 15% | 56% | 36% | 35% | 25% | 15% | 24% | 8% |
| Solar heat gain coefficient | 0.79% | 0.25% | 0.14% | 0.18% | 0.33% | 0.28% | 0.37% | 0.49% | 0.44% | 0.57% |
| Total solar energy rejected % | 21% | 75% | 86% | 82% | 67% | 72% | 63% | 51% | 56% | 43% |
| UV Tdw-ISO @ 300 to 700 nm % | 60% | 11% | 4% | 13% | 26% | 9% | 16% | 26% | 36% | 54% |
| UV light blocked (300 to 380 nm) % | >99% | >99% | >99% | >99% | >99% | >99% | >99% | >99% | >99% | >99% |
| Fade reduction | 27% | 87% | 95% | 84% | 68% | 89% | 80% | 68% | 56% | 34% |
| Specification | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Sentinel Plus 4mil Clear | Sentinel Plus DX 15 | Sentinel Plus DX 5 | Sentinel Plus Silver 20 | Sentinel Plus Silver 35 | Sentinel Plus Stainless Steel 15 | Sentinel Plus Stainless Steel 25 | Sentinel Plus Stainless Steel 40 | Sentinel Plus SX50 OSW | Sentinel Plus SX80 OSW |
| Visible light transmittance % | |||||||||
| 88% | 14% | 5% | 16% | 33% | 13% | 23% | 38% | 47% | 77% |
| Visible light reflectance (exterior) % | |||||||||
| 9% | 42% | 60% | 61% | 41% | 40% | 28% | 18% | 27% | 8% |
| Visible light reflectance (interior) % | |||||||||
| 9% | 17% | 15% | 56% | 36% | 35% | 25% | 15% | 24% | 8% |
| Solar heat gain coefficient | |||||||||
| 0.79 | 0.25 | 0.14 | 0.18 | 0.33 | 0.28 | 0.37 | 0.49 | 0.44 | 0.57 |
| Total solar energy rejected % | |||||||||
| 21% | 75% | 86% | 82% | 67% | 72% | 63% | 51% | 56% | 43% |
| UV Tdw-ISO @ 300 to 700 nm % | |||||||||
| 60% | 11% | 4% | 13% | 26% | 9% | 16% | 26% | 36% | 54% |
| UV light blocked (300 to 380 nm) % | |||||||||
| >99% | >99% | >99% | >99% | >99% | >99% | >99% | >99% | >99% | >99% |
| Fade reduction | |||||||||
| 27% | 87% | 95% | 84% | 68% | 89% | 80% | 68% | 56% | 34% |
Performance Notes:
- Performance results are calculated using the NFRC methodology and LBNL Window software, applied to 1/4″ (6mm) clear glass. These results are intended for estimation purposes only and may vary within industry standards. The data provided is for informational use and may reflect normal manufacturing variations.
- Glare and fade reduction performance results are determined by comparing filmed glass to untreated glazing.
Architectural Sample Pages
- Sentinel Plus 4 Mil Clear Sample Page (SK03144CLRSG)
- Sentinel Plus DX 15 Sample Page (SK0314SPDX15)
- Sentinel Plus DX5 Sample Page (SK0314SPDX5)
- Sentinel Plus SX 50 Sample Page (SK0314SSX50OSW)
- Sentinel Plus SX 80 Sample Page (SK0314SSX80)
- Sentinel Plus Silver 20 Sample Page (SK0314SIL20OSW)
- Sentinel Plus Silver 35 Sample Page (SK0314SIL35OSW)
- Sentinel Plus Stainless Steel 15 Sample Page (SK0314SPSSOSW15)
- Sentinel Plus Stainless Steel 25 Sample Page (SK0314SPSSOSW25)
- Sentinel Plus Stainless Steel 40 Sample Page (SK0314SPSSOSW40)
Glass Retention
CSI Specifications: Solar Control Films 08 87 13
Get in Touch with a Specialist in NYC
Experience the benefits of premium window films! Our experts will guide you every step of the way, from choosing the right film to seamless installation. Ready to upgrade your space? Call us to get started!
